RTS 74 Stratigraphic Panel — Sheet 30
Sheet 30 is tranche 2 of the 4-sheet RTS 74 profile, bounded by Sheets 29 and 31; continuity at both joins is part of the evidence. The source places Seam A1 at about 14–24 m and Seam B2 at about 107–112 m in RTS 74; the wide vertical separation makes continuous depth registration between sheets especially important.
SOURCE-LED TECHNICAL READING
Geological interpretation and evidential boundary
Sheet 30 is tranche 2 of the 4-sheet RTS 74 profile, bounded by Sheets 29 and 31; continuity at both joins is part of the evidence. The source places Seam A1 at about 14–24 m and Seam B2 at about 107–112 m in RTS 74; the wide vertical separation makes continuous depth registration between sheets especially important. Coal markers are transferred only where the low-gamma interval, density response and core-defined roof and floor remain aligned; short excursions may represent a parting, vertical averaging or a depth mismatch. Taken with its neighbouring tranches, RTS 74 Sheet 30 is auditable correlation control—not independent evidence for depositional environment, coal quality or lateral persistence.
